Code:
KWR1
KOROK 78mm panels 400 Kg/m3 no linings
Spec. Details:
Download
STC:
36
FRR:
-/120/60
Wall thickness:
78mm
Frame:
N/A
Cavity:
N/A
CAD drawing:
Code:
KWR2
KOROK 78mm panels 400 Kg/m3 no linings KOROK Fire Flashing is fixed on one side of the top KOROK C-track
Spec. Details:
Download
STC:
36
FRR:
-/120/120
Wall thickness:
78mm
Frame:
N/A
Cavity:
N/A
CAD drawing:
Code:
KWR3
KOROK 78mm panels 400 Kg/m3 1 layer 13mm GIB Fyreline each side
Spec. Details:
Download
STC:
42
FRR:
-/180/180
Wall thickness:
104mm
Frame:
N/A
Cavity:
N/A
CAD drawing:
Code:
KWR3A
KOROK 78mm panels 400 Kg/m3 2 layers 10mm GIB Fyreline direct-fixed one side
Spec. Details:
Download
STC:
42
FRR:
-/180/180
Wall thickness:
98mm
Frame:
N/A
Cavity:
N/A
CAD drawing:
Code:
KWR3B
KOROK 78mm panels 400 Kg/m3 1 layer 19mm GIB Fyreline one side
Spec. Details:
Download
STC:
42
FRR:
-/180/180
Wall thickness:
97mm
Frame:
N/A
Cavity:
N/A
CAD drawing:
Code:
KWR4
KOROK 78mm panels x2 400 Kg/m3 no linings Minimum 50mm between panels
Spec. Details:
Download
STC:
55
FRR:
-/240/240
Wall thickness:
206mm
Frame:
N/A
Cavity:
Minimum 50mm between panels
CAD drawing:
Code:
KWR5
KOROK 78mm panels 400 Kg/m3 1 layer 13mm GIB Noiseline one side 64mm Steel frame one side Minimum 20mm
Spec. Details:
Download
STC:
58
FRR:
-/120/120
Wall thickness:
175mm
Frame:
64mm Steel frame one side
Cavity:
Minimum 20mm
CAD drawing:
Code:
KWR6
KOROK 78mm panels 400 Kg/m3 1 layer 13mm GIB Noiseline one side, 1 layer 13mm GIB Standard other side 64mm Steel frame one side Minimum 20mm
Spec. Details:
Download
STC:
59
FRR:
-/180/120
Wall thickness:
188mm
Frame:
64mm Steel frame one side
Cavity:
Minimum 20mm
CAD drawing:
Code:
FS2
KOROK 78mm panels 400 Kg/m3 no linings KOROK Fire Flashing is fixed on one side of the top KOROK C-track
Spec. Details:
Download
STC:
36
FRR:
-/120/120
Wall thickness:
78mm
Frame:
N/A
Cavity:
N/A
CAD drawing:
Code:
FS3
KOROK 78mm panels 400 Kg/m3 1 layer 13mm GIB Fyreline each side
Spec. Details:
Download
STC:
40
FRR:
-/180/180
Wall thickness:
104mm
Frame:
N/A
Cavity:
N/A
CAD drawing:
Code:
FS4
KOROK 78mm panels x2 400 Kg/m3 no linings Minimum 50mm between panels
Spec. Details:
Download
STC:
55
FRR:
-/240/240
Wall thickness:
206mm
Frame:
N/A
Cavity:
Minimum 50mm between panels
CAD drawing:
Code:
NCS1
KOROK 78mm panels 400 Kg/m3 no linings
Spec. Details:
Download
STC:
36
FRR:
-/120/60
Wall thickness:
78mm
Frame:
N/A
Cavity:
N/A
CAD drawing:
Code:
NCS2
KOROK 78mm panels 400 Kg/m3 1 layer of 13mm GIB Noiseline + R1.8 insulation 64mm Steel frame one side 20mm one side
Spec. Details:
Download
STC:
58
FRR:
-/120/120
Wall thickness:
175mm
Frame:
64mm Steel frame one side
Cavity:
20mm one side
CAD drawing:
